Collar Manufacturer In India

BUTTWELD COLLAR MANUFACTURERS / EXPORTERS / SUPPLIERS IN INDIA

ASME/ANSI B16.9, ANSI B16.28, MSS-SP-43 CARBON, ALLOY, STAINLESS STEEL COLLAR MANUFACTURER / EXPORTER / SUPPLIER IN INDIA

Steel Collar can manufacture and supply collar in standard sizes, as well as in accordance with specification of our customers.

We manufactured various grades of collar includes 304/304L, 316/316L, 321, 347, 317L, 310S, 904L, Duplex, Alloy 201, Alloy 800H, Alloy C276, Cupro Nickel, Alloy 400, Alloy 625 and Alloy 600.

Sarda Pipes & Fittings is a leading Manufacturer, Exporter and Supplier of ASME B16.9 Buttweld Collar. Buttweld Collar manufactured using superior grade raw materials. Sarda Pipes & Fittings supply steel collar and high quality products to international traders, companies and international stockholders in the United States, Europe, Russia, Turkey, Malaysia, the UAE, Saudi Arabia, Iran, Brazil, Chile, Mexico, South Africa, Jordan, Tunisia, Vietnam, Indonesia, Thailand, Singapore, Colombia, and Sri Lanka.

buttweld asme b169 collar manufacturer suppliers India

Collar Production Range

Outside Diameter : 1/2″ – 48″

Wall Thickness: 2-40 mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Value Added Services: Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering

Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel

Manufacturing Standards

ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2

ASTM A403 – ASME SA403 – Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings

ASME B16.9 – Factory-Made Wrought Fittings Buttwelding

ASME B16.25 – Buttwelding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Buttwelding Returns

MSS SP-43 – Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Collar Material Grades

Stainless Steel Collar; ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Collar: ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Collar: ASTM A420 WPL3, A420 WPL6
Alloy Steel Collar: ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Steel Collar: ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462
Nickel Alloy Collar: ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (Inconel 625), UNS 10276 ( HASTELLOY C 276 )

Type	:	Butt weld (BW)
Standards	:	ASME / ANSI - B 16.9 ASTM A403 - ASME SA403 - 'Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings' API 590-605 ASME B16.9 - 'Factory-Made Wrought Buttwelding Fittings' ASME B16.25 - 'Buttwelding Ends' ASME B16.28 - 'Wrought Steel Buttwelding Short Radius Elbows and Returns' MSS SP-43 - 'Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications'
Dimension	:	ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313
Thickness	:	Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Schedule	:	Sch 5 TO Sch XXS.
Size	:	1/2” TO 36”, (Seamless up to 24”), (Welded 8” TO 36”)

Materials and Grade:

Stainless Steel Collar:

ASTM A403 WP316/316L
ASTM A403 WP304/304L
ASTM A182 F316L, 304L
DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Carbon Steel Collar:

ASTM A234 Gr. WPB
ASTM A420 Gr. WPL6
ASTM A105
ASTM A350 Gr. LF2

Nickel Alloy Collar:

Monel 400 & 500,
Inconel 600 & 625,
Incolloy 800, 825,
Hastelloy C22, C276,
Hastelloy,
Nickel,
Monel,
Inconel,
Alloy20,
Copper Nickel
Cupro-Nickel 90/10
Cupro-Nickel 70/30

Alloy Steel Collar:

ASTM a234 wp1 / wp5 / wp9 / wp11 / wp22 / wp91

COLLARS for ANSI 150 flanges
inches	ND	mm	Diameter of lap	Height	Radius of fillet
D			G	h	R
1/2	15	21,34	34,92	5	3
3/4	20	26,67	42,86	6	3
1	25	33,40	50,80	8	3
1 1/4	32	42,16	63,50	8	5
1 1/2	40	48,26	73,00	10	6
2	50	60,32	92,10	10	8
2 1/2	65	73,02	104,80	12	8
3	80	88,90	127,00	12	9
3 1/2	90	101,60	139,70	12	9
4	100	114,30	157,20	14	11
5	125	141,30	185,70	16	11
6	150	168,27	215,90	16	12
8	200	219,07	269,80	18	12
10	250	273,05	323,80	20	12
12	300	323,85	381,00	20	12
14	350	355,60	412,70	25	12
16	400	406,40	469,90	25	12
18	450	457,20	533,40	25	12
20	500	508,00	584,20	25	12
22	550	558,80	641,30	25	12
24	600	609,60	692,10	25	12
Dimension in mm.
The values of radius "R" and height "h" are indicative

ASME B16.9 UNI and DIN flanges

COLLARS for UNI and DIN flanges
inches	ND	mm	Diameter of lap G			Height	Radius of fillet
D			PN 2,5-6	PN 10	PN 16	h	R
1/2	15	21,34	40	45	45	5	2
3/4	20	26,67	50	58	58	8	2
1	25	33,40	60	68	68	8	3
1 1/4	32	42,16	70	78	78	8	3
1 1/2	40	48,26	80	88	88	10	3
2	50	60,32	90	102	102	10	4
2 1/2	65	73,02	110	122	122	12	4
3	80	88,90	128	138	138	12	5
4	100	114,30	148	158	158	14	5
5	125	141,30	178	188	188	14	5
5	125	141,30	178	188	188	14	5
6	150	168,27	202	212	212	16	6
8	200	219,07	258	268	268	18	6
10	250	273,05	312	320	320	20	6
12	300	323,85	365	370	378	20	6
14	350	355,60	415	430	438	25	8
16	400	406,40	465	482	490	25	8
18	450	457,20	520	532	550	25	8
20	500	508,00	570	585	610	25	8
Dimension in mm.
The values of radius "R" and height "h" are indicative
